FAQ

FAQ


What kind of orientation precision should I select?

“It depends on your requirement of orientation time and accuracy. You have the following choices:

Quick orientation (4 points): for fast orientation

Standard orientation (9 points): for most of situations

Precise orientation (20 points): for high-definition system”


When operating and writing on the whiteboard, the position of pen or finger doesn’t match the position of cursor.

“It depends on your requirement of orientation time and accuracy. You have the following choices:

1) The relevant location of projector and whiteboard has been changed. Please re-orient the whiteboard.

2) The projection area has trapezoid distortion, please adjust the projection area, and re-orient the whiteboard.

3) When orienting the whiteboard, the pen or finger is not perpendicular to the surface, please re-orient with correct posture.

4) When orienting the whiteboard, the pen or fingertip missed the green center of the red orienting cross, please re-orient the whiteboard.

5) The filters around whiteboard have been shaded by other objects, such as dust or chalk dust and so on. Please keep filters clean.


When I operate and write on the whiteboard, the system response is slow, or the stroke is intermittent.

1) The computer is not under normal running or the memory is occupied too much. Please close some applications or restart the computer.

2) The operating or writing force is uneven. Sometimes the force is too light to be sensed.

3) Initializing hardware failed. Please reconnect the cable with the board to initialize the hardware again.


When I operate and write on the whiteboard, the system doesn’t respond?

Please reconnect the cable with the board to initialize the hardware again.


What if part of area in the whiteboard cannot work or write?

1) Hardware initialization failed. Please reconnect USB cable and try again when hardware initialization is finished.

2) Make sure that you do not touch the board when the hardware initialization is processing. If you touch the board, it will cause this problem. Please reconnect the USB cable or restart computer then try to operate or write on the board after hardware initialization is finished.

Easy To Operate

Just touch and operate. No additional materials required.

Prepare Lessons

With document camera and teaching software, teacher can quickly upload files to create personalized course wares that are shared with students for review after class.

Active Classroom

Teachers and students can achieve multi-screen interaction with any devices, such as the computer, tablet and mobile phone. Teachers could share class files and make an evaluation of student performance timely.
